SINOTRUK HOWO
HOWO MAX 510 hp · 4×2 AMT
Heavy Trucks · Diesel
New · Left-hand drive · Available to order
- Driving range
- To be confirmed
- Payload
- To be confirmed
- Steering
- LHD
- Battery capacity
- To be confirmed
Specifications depend on the confirmed configuration. Ask us about your destination and operating requirements.
GET TO KNOW THE VEHICLE
Overview
HOWO MAX 510 hp · 4×2 AMT. New, left-hand-drive vehicle available to order. Specifications follow the selected configuration sheet. Confirm destination requirements and final configuration when requesting a quotation.
Specifications
Specifications follow the selected configuration sheet. Missing details remain marked for confirmation.
- Condition
- New
- Supply status
- Available to order
- Steering
- LHD
- Energy type
- Diesel
- Gross vehicle weight
- 18,000 kg
- Payload
- To be confirmed
- Driving range
- To be confirmed
- Battery capacity
- To be confirmed
- Model code
- ZZ4187V391KF1
- Drive configuration
- 4X2
- Rear axle ratio
- 3.08
- Wheelbase
- 3900 mm
- Overall length
- 6.39 m
- Overall width
- 2.53 m
- Overall height
- 3.82 m
- Vehicle weight
- 6.8 t
- Maximum speed
- 89 km/h
- Permitted towing mass
- 35 t
- Engine displacement
- 13.02L
- Engine model
- SINOTRUK MC13H.51-61
- Engine output
- 378 kW
- Engine horsepower
- 510 hp
- Engine torque
- 2400 N·m
- Torque speed
- 950-1400 rpm
- Rated speed
- 1800 rpm
- Emissions standard (source designation)
- China VI
- Transmission model
- SINOTRUK HW25716XAL
- Transmission
- AMT
- Forward gears
- 16 gears
- Reverse gears
- 2
- Fuel tank capacity
- 1000L
- Seats
- 2 seats
- Cab rows
- Extended cab
- Permitted front axle load
- 6500 kg
- Permitted rear axle load
- 11500 kg
- Tyres
- 12R22.5 18PR
- Tyre count
- 6
- ABS
- Listed as equipped
- Wheel differential lock
- Listed as equipped
- Multifunction steering wheel
- Listed as equipped
- Air conditioning
- Automatic
- Electric windows
- Listed as equipped
- Electric mirrors
- Listed as equipped
- Heated mirrors
- Listed as equipped
- Reversing camera
- 360° camera
