Photos show reference vehicles and may differ from this configuration. Specifications follow the listed configuration sheet.
BYD
T5 Wealth · 18.3 kWh Range-extender Dropside
Light Trucks · Range-extender hybrid
New · Left-hand drive · Available to order
- Driving range
- 50 km (CLTC; range basis to be confirmed)
- Payload
- 1,515 kg
- Steering
- LHD
- Battery capacity
- 18.3 kWh
Specifications depend on the confirmed configuration. Ask us about your destination and operating requirements.
GET TO KNOW THE VEHICLE
Overview
T5 Wealth · 18.3 kWh Range-extender Dropside. New, left-hand-drive vehicle available to order. Specifications follow the selected configuration sheet. Confirm destination requirements and final configuration when requesting a quotation. The sheet lists 50 km CLTC range without specifying the range basis; this is not presented as combined fuel-and-electric range.
Specifications
Specifications follow the selected configuration sheet. Missing details remain marked for confirmation.
- Condition
- New
- Supply status
- Available to order
- Steering
- LHD
- Energy type
- Range-extender hybrid
- Gross vehicle weight
- 4,495 kg
- Payload
- 1,515 kg
- Driving range
- 50 km (CLTC; range basis to be confirmed)
- Battery capacity
- 18.3 kWh
- Model code
- BYD1040A3HEV41
- Trim
- Wealth
- Drive configuration
- 4X2
- Wheelbase
- 3360 mm
- Overall length
- 5.995 m
- Overall width
- 2.115 m
- Overall height
- 2.545 m
- Vehicle weight
- 2.8 t
- Maximum speed
- 100 km/h
- Engine displacement
- 1.5L
- Engine model
- BYD476ZQG
- Engine output
- 104 kW
- Engine horsepower
- 141 hp
- Emissions standard (source designation)
- China IV
- Body type
- Dropside
- Cargo body length
- 4.005 m
- Cargo body width
- 2.1 m
- Cargo body height
- 0.4 m
- Cab width
- 2050 mm
- Seats
- 3 seats
- Cab rows
- Single cab
- Permitted front axle load
- 2020 kg
- Permitted rear axle load
- 2475 kg
- Tyres
- 7.00R16LT 10PR
- Tyre count
- 6
- Motor model
- TZ200XSY
- Motor type
- Permanent magnet synchronous
- Motor rated power
- 70 kW
- Motor peak power
- 150 kW
- Battery brand
- FinDreams
- Battery chemistry
- Lithium iron phosphate (LFP)
- Charging method
- DC fast charging
- ABS
- Listed as equipped
- Multifunction steering wheel
- Listed as equipped
- Remote key
- Listed as equipped
- Central locking
- Listed as equipped
- Front brakes
- Disc
- Rear brakes
- Drum
- Charging connector
- To be confirmed
- Charging time and SOC window
- To be confirmed
Gallery
Your application
Tell us what the vehicle needs to do. Suitability must be checked against the confirmed configuration.
Downloads
A confirmed brochure and specification sheet are not available yet.
Request vehicle informationFrequently asked questions
How do I confirm the specifications?
Include the model and your operating requirements in your enquiry. Confirm the exact configuration before making a purchase decision.
Is this vehicle suitable for my country?
Suitability and local requirements need to be checked for your destination. Share your country, intended use and steering preference.
How do I request a quote?
Open Request a Quote and fill in your requirements. At this preview stage, the form downloads a local draft; online submission is not yet available.
